Lithium Battery Pack Cell Balancer for Electric Vehicles LAUNCH SMARTSAFE iSmartEV EB480

$9,600

Category:

Description

iSmartEV EB480 is mainly used for lithium battery pack charge & discharge test and equalizing maintenance, suitable for various voltage levels.

Working conditions: No corrosive, no explosive, no electrical breakdown air or conductive dust.

Lithium battery pack charge test
Lithium battery pack discharge test
Equalizing maintenance

Features

  • 48 Equalizing Channel&Single Core Equalizing Design
    Support the equalization of up to 4 groups of modules, and each group can equalize up to 12 strings of cores; Support single core precise equalization
  • Intelligent Cell Equalization
    Support ternary lithium, lithium iron phosphate, lithium manganate and lithium titanate batteries; Support parameter setting, preset the voltage range according to the battery type, and automatically switch the charging and discharging mode to effectively solve the battery consistency problem
  • High Precision Equalization
    Support high-precision collection of single cell voltage parameters, effectively improve battery pack performance
  • Multiple Protection and Security
    It has the mechanism of reducing working currently to achieve the goal and makes the voltage of cells in the battery pack infinitely close to the target threshold during the test
  • Visualization of Equilibrium Process
    Differential comparison between “before” and “after” can export equalization data; The equalization process monitors the voltage parameters and equalization status of every single cell in real-time

Specifications

Parameters
Power input
Single-phase AC 90-264V / 40~60Hz
Charge and discharge power
Max 1200W
Charge and discharge voltage range
1.8~4.5V
Battery interface
16Pin, 24Pin
Voltage detection accuracy
±0.1% FS±2mV (maximum range 5V)
PC data communication
TCP/IP, USB-Device
Charge and discharge current range
0.1~5A MAX
Wireless communication
WiFi
Current detection accuracy
±1% FS±0.05A (maximum range 5A)
Charge control
Constant current charging + constant voltage charging
Number of channels
2×24
Discharge mode
Constant current discharging
Display
7-inch TFT LCDscreen,resolution 800×480
Protection function
Input over-current protection, over-voltage
protection, output over-current protection,
over-temperature protection
